| ATEX Zone | 1 |
| ATEX certification | EX II 2G Ex eb ib pxb IIC T6 Gb |
| IECEc certification | EX eb ib pxb IIC T6 Gb |
| Housing | Stainless steel |
| Image sensor / number of effective pixels | CMOS / 2130k Pixel |
| Output Pixel (HxV) | 1920x1080 |
| Signalsysestem | 1080i/60 |
| Minimum illuminance | 0.01 lx |
| Optical zoom | 30x |
| Digital zoom | 12x |
| Focus | Automatic or manual |
| Viewpoint | 63.7° (wide) to 2.3° (tele) |
| Minimum object distance | 10 mm (wide) to 1200 mm (tele) |
| Video output | Y / Pb / Pr |
| Range - PAN | Infinite |
| Range - TILT | 220° (± 110°) |
| Lighting | 4x LED spots |
| Luminous flux | --- |
| Dimensions (LxWxø) | 250x117x135 mm |
| Weight | 5 kg |
| Operating temperature | +1°C to +50°C |
| Waterproof / Water depth | 0.6 bar / 6 m |
| Radiation tolerance | --- |
| Total dose | --- |
| Accessories (optional) | --- |
| Features | Integrated detent coupling for PAN & TILT, line laser |
Inspection cameras
VT 1000 PTZL HD EX ATEX
Achieve the best viewing results with our camera for ATEX Zone 1
- High-quality and particularly reliable results thanks to Full HD camera with 30x optical zoom and pan-tilt function
- Bright illumination of tanks, pipes or other objects thanks to built-in LED lighting
- Can also be used in potentially explosive or submerged areas, thanks to a waterproof and explosion-proof housing
- Measurement possible directly in the image due to integrated double line laser
Product overview
Do you need the right equipment to inspect dark or hard-to-reach places? Our waterproof full HD inspection camera offers the optimal solution: Thanks to numerous functions as well as comprehensive expansion options, it enables best results especially in risky areas, such as the Ex-area Zone 1.
Key features
- Explosion protection - ATEX Zone 1 (EX II 2G Ex eb ib pxb IIC T6 Gb)
- Explosion protection - IECEc rating (EX eb ib pxb IIC T6 Gb)
- Robust design in stainless steel
- Pan & Tilt with detent coupling
- Zoom lens 30x optical / 12x digital
- 1080i / 60 fps Full HD resolution
- Integrated LED lighting and line laser
- Waterproof up to 6 m
Documents
Areas of application
All underwater inspections and monitoring tasks
Nuclear applications (loading - unloading - maintenance)
Industrial applications
Applications in the field of nuclear decommissioning
