| Housing | Stainless steel |
| Image sensor / number of effective pixels | 1/3" CMOS |
| Horizontal resolution | 600 TVL |
| Signalsysestem | PAL/NTSC |
| Minimum illuminance | 0.001 lx |
| Optical zoom | N/a |
| Digital zoom | N/a |
| Focus | Manual (motorised) |
| Viewpoint | --- |
| Minimum object distance | --- |
| Video output | CVBS |
| Range - PAN | N/a |
| Range - TILT | N/a |
| Lighting | 12x LED |
| Luminous flux | ~108 lm |
| Dimensions (ø x L) | 25x78 mm |
| Weight | --- |
| Operating temperature | --- |
| Waterproof / Water depth | 5 bar / 50 m |
| Radiation tolerance | 5,500 rad/h (55 Gy/h) / 2,100 rad/h (21 Gy/h) |
| Total dose | 30,000 rad (300 Gy) / 80,800 rad (808 Gy) |
| Accessories (optional) | --- |
| Features | --- |
Inspection cameras
VT 25 FL inspection camera
Best viewing results in confined spaces, thanks to 25mm miniature colour camera
- The camera is available in colour or black and white options and can also be equipped with infrared illumination
- Very high picture quality thanks to horizontal resolution with 600 TV lines
- Versatile, due to extremely compact dimensions, with a diameter of only 25 mm
- Optimally mountable, thanks to very light weight
Product overview
Are you looking for the right equipment specifically for your confined space inspections? With its small size and waterproof design, this miniature colour camera is ideal for underwater inspections, vessel and boiler inspections, and foreign parts recovery. The integrated LED illumination and remote focusing guarantee excellent results even in dark and hard-to-reach areas.
Key features
- Small and robust design made of stainless steel
- Outer diameter of 25 mm
- Radiation-resistant
- PAL/NTSC
- Integrated LED lighting
- Waterproof up to 50 m
Documents
Areas of application
Pipeline inspection
Underwater inspection
Remote controlled manipulators
Recovery of foreign bodies
Difficult to access areas
Industry
Sewer inspections
Inspection of nuclear facilities
